TDF Flange Forming Machine
TDF-T12 trans-verse flange system is one of the two universal flange manufacture system in the world.Through summarizing the experience of installation and manufacture of flange system both at home and abroad,our technicians have designed the advanced machine-TDF-T12 Trans-verse Flange machine.Duct manufacture line can be consisted by TDF series and other products-shear,notching machine,bending
grooving machine,folding machine,Pitsburgh lock machine,duct comer machine,feeding machine and act.It can produce standard and reliable duct.
Following are the features:
Detailed research and discussion while designing can not only ensure the safe and reliability of machine,but also make operation easier.
Duct and flange forming together,(the working procedures of flange's producing and welding have saved have saved),which not only improve
the product quality but also lower the cost.
-+
Contact Us

3-pieces  asynchronous  motor;3KW、380V、1430tun/min

Reducer VR:1:10;

Forming  speed:16m/min

Dimension:L×W×H=2740×620×1200mm

Weight:1100kg

Working thickness:1)0.5~1.2mm thickness galvanized

sheet or low-carbon steel is usedin roling flange.

2)1.0mm thickness galvanized sheet is used in rolling clip


型号


电机功系

5

骨形形状

"a'尺寸 "a"size

(mm)

重量

Weight (kg)

外型尺寸

Dimension size

国 H

9426000

T-12

3

0.5-1.2


35-0.5

1100

2800X600X1120

9426100

T-15

4

Stainless steel


34-0.5

1200

3200X750x1000

9426120

MT15 MT30

4

。


35-0.5

3000

3200X900X1000

9427000

2-T12

4

0.6~1.2

35-0.5

2500

2800x2700x1100

9426140

L-TDF-10

5.5

0.8-1.0

35-0.5

3000

4500x750x¹100

Quality and After-sale Assurance

Our company has a modern scientific research center, advanced production equipment and industry talents. Through continuous innovation, it has always been in the leading position in the industry. The Kunjiu team continues to meet the needs of the market through joint efforts.

We promises that the name, model, specification and quantity of the equipment comply with the technical agreement. Guarantee that the equipment is excellent in craftsmanship, free from defects in design, materials, and workmanship, and meet customer needs.

we will provide service on installation and commissioning , no worry about after sales.

All equipment is delivered after passing the quality inspection and debugging.

Trade Term

Price Terms: EXW, FOB, CIF
Payment Terms: 30% as deposit, and 70% before delivery
Lead Time: 20-90 days depends on machine size and quantities
